Flatwork Ironers

ماشین آلات لاندری-سیستم های اتوکشی
  Vela 3218 Vela 5015 Vela 5515 Vela5518 Vela 5520 Vela 5525 Vela 5530
Heating Type   Electric Electric/Steam Gas Elc/Stm/Gas Elc/Stm/Gas Elc/Stm/Gas Elc/Stm/Gas
Cylinder Diameter (mm) 320 500 550 550 550 550 550
Cylinder Width (mm) 1.800 1.500 1.500 1.800 2.000 2.500 3.000
Ironing Capacity (kg/hr) 24 40 / 40 50 42 / 42 / 52 45 / 45 / 55 50 / 50 / 60 55 / 55 / 65
Working Speed (m/min) 2-6 3,5 - 10,5 3,5 - 10,5 3,5 - 10,5 3,5 - 10,5 3,5 - 10,5 3,5 - 10,5
Motor Power (Kw) 0,37 0,55 0,55 0,55 0,55 0,55 0,55
Fan Motor Power (Kw) 0,37 0,37 0,37 0,37 0,37 0,37 0,37
Electric Heating Power (Kw) 24 27 -- 22,5 22,5 27 31,5
Steam Consumption (kg/hr) -- 35 -- 40 45 50 55
Gas Heat Power (Kcal/hr) -- -- 22.280 23.700 26.350 28.900 31.570
Width (mm) 2.530 2.230 / 2.230 2.390 2.530 / 2.530 / 2.690 2.730 / 2.730 / 2.890 3.230 / 3.390 / 3.390 3.730 / 3.890 / 3.890
Depth (mm) 905 1.150 / 1.200 1.200 1.150 / 1.200 / 1.200 1.150 / 1.200 / 1.200 1.150 / 1.200 / 1.200 1.150 / 1.200 / 1.200
Height (mm) 990 1.355 / 1.355 1.675 1.355 / 1.355 / 1.675 1.355 / 1.355 / 1.675 1.355 / 1.355 / 1.675 1.355 / 1.355 / 1.675
Weight (kg) 500 810 810 885 930 1.050 1.170
    Vela 6530 Vela 7520 Vela 7525 Vela 7530 Vela 7532 Vela 9530 Vela 12030
Heating Type   Elc/Stm/Gas Elc/Stm/Gas Elc/Stm/Gas Elc/Stm/Gas Elc/Stm/Gas Elc/Stm/Gas Elc/Stm/Gas
Cylinder Diameter (mm) 650 750 750 750 750 950 1.200
Cylinder Width (mm) 3.000 2.000 2.500 3.000 3.200 3.000 3.000
Ironing Capacity (kg/hr) 65 / 65 / 80 65 / 65 / 80 74 / 74 / 90 80 / 80 / 100 90 / 90 110 / 150 140 / 200
Working Speed (m/min) 4/12 4,5 / 13,5 4,5 / 13,5 4,5 / 13,5 3/9 6/18 7/22
Motor Power (Kw) 0,55 0,55 0,55 0,55+0,37 0.55 + 0.46 3 / 2x1,5 3 / 2x1,5
Fan Motor Power (Kw) 0,37 0,37 0,37 2x0,37 0.37 3+0,37 3+0,37
Electric Heating Power (Kw) 32 30 36 40 54 72 84
Steam Consumption (kg/hr) 65 65 70 75 80 100 150
Gas Heat Power (Kcal/hr) 28.000 26.350 31.570 35.100 41.250 66.000 82.500
Width (mm) 3.835 / 3.925 / 3.925 2.835 / 2.995 / 2.995 3.335 / 3.425 / 3.425 3.700 / 3.870 / 3.950 4.150 4.070/4.070/4.150 4.210
Depth (mm) 1.400 / 1.450 / 1.450 1.400 / 1.450 / 1.540 1.400 / 1.450 / 1.540 1.760 (2337) 1.480 2.020(2.800) 2.100 (2.870)
Height (mm) 1.800 / 1.800 / 2.120 1.850 / 1.800 / 2.170 1.850 / 1.850 / 2.170 1.850 1.630 2.355 2.353
Weight (kg) 1.570 1.475 1.600 1.725 1.920 2.525 / 2.325 3.990 / 3.640
